How to Use the XROS 5: Settings, Controls and Setup Guide

Updated On25 October 2026by : shane margereson
A silver Vaporesso XROS 5 pod kit with its colour screen showing PWR mode, for our guide to its settings, controls and setup

The XROS 5 has one button. The number of clicks within 2 seconds decides what it does: 1 click fires and 2 open the themes. 3 set the mode or wattage, 4 open the settings and 5 turn it on or off.

Shop the Vaporesso XROS 5 kit and XROS pods.

The XROS question our support team gets most is which pods fit. The XROS 5 takes any XROS pod. This guide covers each click in turn, using Vaporesso's own XROS 5 manual and product pages. It covers the XROS 5 Mini as well.

The Vaporesso XROS 5 pod kit page has the full specs and colours.

Every current XROS kit is in the Vaporesso XROS range.

Pods, coils and the rest of the brand are in our Vaporesso range.

Jump to a section:

Settings and Controls

Turn It On and Off

Click the button 5 times within 2 seconds to turn the XROS 5 on. Do the same again to turn it off.

Once it is on, you can vape two ways. It is both button-activated and draw-activated. You can press the button while you inhale, or just inhale through the mouthpiece.

The XROS 5 Mini is different: it has no on and off steps and simply fires when you draw. The XROS 5 Mini section explains it.

Button Functions

Vaporesso XROS 5 button functions: 1 press fires, 2 clicks themes, 3 clicks mode or wattage, 4 clicks settings, 5 clicks on or off

Vaporesso sum up the buttons as 1, 2, 3, 4, 5. Click the number of times below within 2 seconds:

Clicks

What it does

1 press

Fires the kit (press and hold while you inhale)

2 clicks

Theme settings

3 clicks

Mode (NOR, PWR or ECO), or wattage with a 0.4Ω pod

4 clicks

Settings: screen lock, button on or off, puff clear and animation

5 clicks

Turns the XROS 5 on or off

In the theme and settings menus, a single click moves to the next option. Press and hold for 2 seconds to confirm it. On the mode screen you wait 3 seconds instead and it saves.

What NOR, PWR and ECO Mean

NOR stands for Normal, PWR for Power and ECO for Eco. They are the XROS 5's three power levels. They appear when any pod from 0.6Ω to 1.2Ω is fitted.

To change modes on the XROS 5:

  1. Click the button 3 times within 2 seconds.
  2. Click the button to move between PWR, NOR and ECO.
  3. Stop on the one you want and wait 3 seconds. The kit saves it.

Vaporesso do not publish the wattage behind each mode. Our advice is to try all three for a few puffs each and keep the one you like. Each one feels different on each pod.

Change the Wattage

You can only set a wattage on an XROS 5 with the 0.4Ω pod fitted. With any other XROS pod, the same 3 clicks give you the NOR, PWR and ECO modes above instead.

With a 0.4Ω pod:

  1. Click the button 3 times within 2 seconds to open the power setting.
  2. Click the button again to change the wattage.
  3. The range is 15W to 30W, in 0.5W steps.

Vaporesso's XROS pod page lists 25W for its 0.4Ω pod, so 25W is a sensible place to start.

Change the Screen Theme

The XROS 5 has a 0.88 inch screen with six themes. Vaporesso's page shows them as Space, Watch, Rainbow, Black, White and Pink.

To change the theme:

  1. Click the button 2 times within 2 seconds.
  2. Click to move through the themes.
  3. Press and hold the button for 2 seconds on the one you want to confirm it.

To turn the screen animation on or off:

  1. Click the button 4 times within 2 seconds to open the settings.
  2. Click to move to the animation setting.
  3. Press and hold for 2 seconds to confirm.

Lock and Unlock

The XROS 5 has two locks in the 4-click settings menu. SCREEN LOCK locks the screen. BUTTON ON/OFF turns off the button-activate function, so a press in a pocket will not fire it. Draw activation is a separate function.

Screen lock

  1. Click the button 4 times within 2 seconds.
  2. Click to SCREEN LOCK.
  3. Press and hold for 2 seconds to lock.
  4. To unlock, click the button 4 times within 2 seconds.

Turning the kit on and off with 5 clicks still works while the screen is locked.

Button lock (BUTTON ON/OFF)

  1. Click the button 4 times within 2 seconds.
  2. Click to BUTTON ON/OFF.
  3. Press and hold for 2 seconds to turn the fire button off. Do the same to turn it back on.

Reset the Puff Counter

Puff clear sets the kit's puff count back to zero. To do it:

  1. Click the button 4 times within 2 seconds to open the settings.
  2. Click to the puff clear option.
  3. Press and hold for 2 seconds to confirm.

The XROS 5 manual has no puff history option. The XROS Pro 2 has one, as the XROS Pro 2 section explains.

Pods and E-Liquid

How to Fill and Refill a Vaporesso Pod

Vaporesso pods fill in one of two ways. XROS pods fill from the top, under the mouthpiece. Luxe X and Luxe XR Max pods fill through a silicone plug on the bottom.

The XROS 5 and XROS 5 Mini fill from the top. The steps to fill them are:

  1. If it is a new kit, pull the pod out and tear the sticker off the pre-installed pod.
  2. Snap off the mouthpiece.
  3. Squeeze the e-liquid into the filling hole. It is 3.5mm across.
  4. Put the mouthpiece back and make sure it is shut firmly.
  5. Push the pod back into the kit.
  6. On a first fill, wait 5 minutes before you vape so the coil can prime.

The pod holds 2ml in the UK, which is the TPD version. Fill below the top, so the mouthpiece closes without pushing liquid out.

Our advice is to refill before the pod gets close to empty. You do not need to empty it first. The 5 minute wait is only for a new pod's first fill. Our guide on how to prime a vape coil explains why the 5 minute wait matters.

For bottom fill pods on the Vaporesso Luxe range, the steps to fill them are:

  1. Take the pod out of the kit.
  2. Pull the silicone plug out of the bottom of the pod.
  3. Fill the e-liquid through the hole.
  4. Push the plug back in firmly once you have filled it.
  5. Wait 5 minutes so the e-liquid can soak into the coil completely.

XROS 5 Kits and Pods

The XROS 5 and XROS 5 Mini, and the current XROS pods that fit them.

Vaporesso XROS 5 Pod Vape Kit
Vaporesso XROS 5 pod vape kit in the four leather finishes, Black, Grey, Brown and Red Leather, with the 0.88 inch colour screen

Vaporesso XROS 5 Pod Vape Kit

£19.99
3 DOJOLIQ Included
Quick Buy
Vaporesso XROS 5 Mini Pod Vape Kit
Vaporesso XROS 5 Mini pod vape kit in Retro Orange, Mist White, Retro Pink and Mist Black

Vaporesso XROS 5 Mini Pod Vape Kit

£14.99
3 DOJOLIQ Included
Quick Buy
Vaporesso XROS COREX 3.0 Pods
Vaporesso XROS COREX 3.0 pods, four to a pack, shown out of the box

Vaporesso XROS COREX 3.0 Pods

£9.99
Quick Buy

Empty a Pod

Vaporesso's manual does not cover emptying a pod, so this is how we do it when changing flavour:

  1. Pull the pod out of the kit.
  2. Snap off the mouthpiece.
  3. Tip the pod over a sink or tissue and let the liquid drain out of the filling hole.
  4. Wipe the top of the pod dry, then refill and refit the mouthpiece.

The coil stays soaked in the old liquid. So the first few puffs of a new flavour can taste of both. In our experience this fades after a few puffs.

What E-Liquid to Use

Vaporesso say XROS pods suit both freebase and nic salt e-liquids. They describe the XROS range as made for mouth to lung through to restricted direct lung vaping. Their general FAQ also says a thicker, high VG e-liquid can cause coil burning.

They do not give a VG/PG ratio for XROS pods, so this part is our advice: a 50/50 e-liquid suits them well, and many nic salt e-liquids are made at 50/50.

For flavour ideas, see our pick of e-liquids that suit the XROS 5.

How Long the Pods Last

Vaporesso do not give a figure for how long an XROS pod lasts. It depends on how much you vape and what you vape. Change the pod when:

  • The flavour fades and does not come back after a refill.
  • You get a burnt taste on a full pod.
  • It makes less vapour than it did.
  • It starts to leak or spit with nothing else wrong.

Our guide to how long Vaporesso pods and coils last covers what shortens pod life.

The XROS 5 takes XROS pods from 0.4Ω to 1.2Ω, and the manual also lists 0.7Ω. The current pods are the Vaporesso XROS COREX 3.0 pods.

Vaporesso's XROS 5 page lists the 0.4Ω pod as compatible. Their newer kit pages say every XROS pod has now moved to COREX 3.0. The COREX 3.0 pods come in 0.4Ω to 1.2Ω.

Battery, Airflow and Screen Messages

Charging and the Battery Level

The XROS 5 has a 1500mAh battery and charges through USB-C. Vaporesso's lab figure is 80% in 20 minutes on a 5V/3A charger.

  1. Use the USB-C cable that came in the box.
  2. Plug it into a standard USB charger. The manual lists 9V/2A and 5V/3A charging.
  3. The screen plays a charging animation and shows the current charge.
  4. When it is full, the kit stops charging on its own, although the screen stays on the charging display.

To check the battery at any time, click the button once or refit the pod and the screen lights up. Vaporesso also ask you not to leave the kit charging unattended.

Airflow Settings, Mini Included

Both the XROS 5 and the XROS 5 Mini have an airflow toggle on the back of the kit. Vaporesso say it covers everything from a tight mouth to lung draw to a looser restricted direct lung draw.

  1. Find the toggle on the back of the kit.
  2. Slide it all the way one way and take a draw. Then slide it all the way the other way and take another.
  3. Settle wherever the draw feels right to you.

Vaporesso do not say which way is tighter, which is why we suggest trying both ends.

On the XROS 5 Nano, the airflow toggle is on the side of the kit.

Screen Messages

If the XROS 5 stops and shows a message, it is one of its protections. The manual gives what each message means, and the fixes are our advice:

On screen

What it means

CHECK ATOMIZER

No pod, or the pod is not connecting. Refit it and clean the contacts

SHORT ATOMIZER

A short circuit in the pod. Try another pod

OVER HEAT

The kit is too hot. Let it cool

BATTERY LOW

Charge the kit

OVER TIME

It fired for 8 seconds in one go and cut out. Stop and fire again

For fixes step by step, our Vaporesso troubleshooting guide covers every message and light.

Other XROS Kits

The newer Vaporesso XROS 6 takes the same pods. Our XROS 6 review and XROS 6 vs XROS 5 comparison explain whether it is worth the upgrade.

XROS 5 Mini

The Vaporesso XROS 5 Mini pod kit has no screen, and Vaporesso's manual shows no button on it. It is draw-activated, so you just inhale through the mouthpiece and it fires. There are no on and off steps and no modes to set.

  1. Pull out the pre-installed pod and tear off its sticker.
  2. Snap off the mouthpiece and fill through the filling hole.
  3. Shut the mouthpiece firmly and push the pod back in.
  4. Wait 5 minutes on the first fill.
  5. Set the airflow toggle on the back, then inhale to vape.

If you want to be sure it cannot fire in a bag, take the pod out. The UK kit comes with one 0.6Ω pod.

XROS 5 Mini battery lights

The Mini shows its battery with four lights. Vaporesso do not give colours, only how many are lit:

Lights on

Battery

4

75 to 100%

3

50 to 75%

2

25 to 50%

1

25% or less

While charging, the lights flash from 1 to 4. When it is full, all four stay on, then go out after 10 minutes. It charges through USB-C at 2A.

XROS 5 Mini flashing lights

All 4 lights flash

What it means

5 times

Short circuit in the pod

4 times

No pod, or the pod is not connecting

3 times

Too hot

2 times

Battery low, charge it

4 times, then 1 slow pulse

You drew for 8 seconds and it cut out

XROS Pro 2 Wattage

The Vaporesso XROS Pro 2 pod kit uses the same 1 to 5 click layout as the XROS 5. So most of this guide works for it too. To change the wattage with a 0.4Ω pod:

  1. Click the button 3 times within 2 seconds.
  2. Click again to change the wattage, from 15W to 30W in 0.5W steps.

With a 0.6Ω to 1.2Ω pod, the same 3 clicks open PWR, NOR and ECO. Click to choose, then wait 3 seconds to save and exit.

Where the Pro 2 differs from the XROS 5:

  • The screen lock is called SCREEN LK. It is in the same 4-click settings menu.
  • It has PUFF HISTORY. In the 4-click settings, choose PUFF HISTORY and hold for 2 seconds. Each click then switches between 1 day, 7 days and 30 days. Hold for 2 seconds to leave.
  • Its six themes are different: Meter, Flower, Planet, Basic, Bubble and Light, on a 0.96 inch screen.
  • A bigger battery. 2000mAh, charging at 5V/2A.

XROS 6 and XROS 5 Nano

The XROS 6 and XROS 5 Nano only partly follow the XROS 5 click layout. Check the steps below before you use the ones above.

XROS 6: press twice to open the menu, which has THEME, PRIME COIL, POWER and SETTING, with POWER SAVE inside THEME. Three presses change the mode or wattage, four lock or unlock the screen, and five turn it on or off. Vaporesso say the screen on UK kits differs from the standard version. So a UK XROS 6 may not match the manual. It needs only a 1 minute wait on a first fill. The Vaporesso XROS 6 pod kit page has more.

XROS 5 Nano: it has a touchscreen and fires only when you draw. With a 0.6Ω to 1.2Ω pod, swipe right on the home screen. Then tap the arrows to choose P, N or E. With a 0.4Ω pod, tap the plus or minus icons to set the power. Press the button once to lock the screen. To unlock, press it, then press and hold the pattern and slide up.

The airflow toggle on the Vaporesso XROS 5 Nano pod kit is on the side, not the back.

Newer Vaporesso XROS Kits

If you are thinking of a newer kit, these are the latest XROS models.

Vaporesso XROS 6 Pod Vape Kit
Five Vaporesso XROS 6 pod kits in a line, each with the 0.88 inch screen reading 30W, from a range of eighteen finishes

Vaporesso XROS 6 Pod Vape Kit

£23.99
3 DOJOLIQ Included
Quick Buy
Vaporesso XROS 6 Mini Pod Vape Kit
Vaporesso XROS 6 Mini pod kit shown across the colour range on a white background

Vaporesso XROS 6 Mini Pod Vape Kit

£16.49
3 DOJOLIQ Included
Quick Buy
Vaporesso XROS Pro 2 Pod Kit
Vaporesso XROS Pro 2 pod kit shown in five finishes side by side, each with the 0.96 inch screen reading 30W

Vaporesso XROS Pro 2 Pod Kit

£23.99
3 DOJOLIQ Included
Quick Buy
Vaporesso XROS 5 Nano Pod Vape Kit
Three Vaporesso XROS 5 Nano pod kits side by side, showing the square body and the circular touchscreen reading 30W

Vaporesso XROS 5 Nano Pod Vape Kit

£19.49
1 DOJOLIQ Included
Quick Buy
Vaporesso XROS Mini Retro Pod Vape Kit
Sold Out
Vaporesso XROS Mini Retro pod kit shown across the colour range on a white background

Vaporesso XROS Mini Retro Pod Vape Kit

£9.99
3 DOJOLIQ Included

Frequently Asked Questions

NOR stands for Normal. On the XROS 5 and XROS Pro 2, a 0.6Ω to 1.2Ω pod lets you choose PWR, NOR or ECO. Click the button 3 times within 2 seconds, click to choose, then wait 3 seconds to save.

You can only set a wattage with the 0.4Ω pod. Click the button 3 times within 2 seconds, then click to change it from 15W to 30W. With any other XROS pod, the same 3 clicks choose NOR, PWR or ECO instead.

Pull the pod out, snap off the mouthpiece and squeeze e-liquid into the filling hole. Put the mouthpiece back firmly. On a first fill, wait 5 minutes before vaping so the coil can prime.

Click the button 4 times within 2 seconds, click to SCREEN LOCK and hold for 2 seconds. To unlock, click 4 times within 2 seconds. To stop the button firing, choose BUTTON ON/OFF in the same menu and hold for 2 seconds.

Puff clear sets the kit's puff count back to zero. On the XROS 5, click the button 4 times within 2 seconds, then click to puff clear. Press and hold for 2 seconds to confirm.

Click the button 2 times within 2 seconds, then click through the six themes. Press and hold for 2 seconds on the one you want. The XROS 5 Mini has no screen.

You do not need to, as the XROS 5 Mini fires when you inhale. If nothing happens, check the pod is pushed fully in and charge the kit.

With a 0.4Ω pod fitted, click the button 3 times within 2 seconds. Then click to change the wattage, from 15W to 30W in 0.5W steps. With a 0.6Ω to 1.2Ω pod, the same 3 clicks choose PWR, NOR or ECO.

About the author - Shane Margereson

Tags:GuidesPodsVape Kits

Related Articles

The parts of a vape and the cleaning tools needed
Guides
.by : shane margereson

How to Clean a Vape: Pods, Tanks, Coils and Mouthpieces

How to clean a vape properly: pods, tanks, coils and mouthpieces, what must never get wet, and the five-minute weekly routine that makes a kit last.

How to refill a vape pod showing hands filling e-liquid into a removable pod tank next to a compact pod kit on a wooden surface.
Guides
.by : shane margereson

How to Refill a Vape Pod and Choose Your First Pod Kit

In this blog we will discuss how to choose your first pod vape kit, what they are and what vape juice to use you will find everything in this helpful guide written with someone with 11 years experience.

Comparison of prefilled and refillable vape kits featuring a blue Al Fakher device and a teal VOOPOO Argus pod kit with text Switching From Disposable Vapes: Prefilled or Refillable?
Guides
.by : shane margereson

Switching From Disposable Vapes: Prefilled or Refillable?

In this blog we'll look at how to switch from disposable vapes to pod kits, the different types of pod kits available, and some tips to make the transition easier.
